| The 7.5kW/20kW motor test system ordered by Korean customers has been installed and commissioned, an |
| Hits：6799 AddTime：2022/4/28 9:40:47 |
| The 7.5kW/20kW motor test system ordered by a Korean customer, through video guidance with the customer, the customer completed the installation and commissioning by himself, and was highly praised by the customer! This test system is equipped with two separate test benches: 7.5kW-50N.m/20kW-200N.m, and the maximum speed can reach 8000rpm. The test bench part of the motor installation platform under test is designed to be multi-dimensional adjustable, which can adapt to flange-mounted motors and base-mounted motors, and the motor installation and adjustment are convenient. When replacing a different type of motor under test, it is only necessary to replace the matching connection fixture, and the product series test can be carried out. Two sets of test benches are equipped with one set of variable frequency power supply and two sets of separate power feedback systems, which can effectively save the electric energy used during testing. In the detection control part, two sets of test benches use one set of detection system. The matching is a vertical cabinet, which occupies a small area and is compact in space. The test software adopts the "Motor Test Software" independently developed by our Lanling Technology, supporting torque, speed and power acquisition instrument, data acquisition module, etc., which can measure the current, voltage, input power of the motor input, and the torque, speed, and output of the motor output. Power, motor efficiency, motor temperature, etc. The data in the test process can be generated into Word, Excel or PDF format files, the data can be saved, edited, printed, etc.; and the test curve can be generated; the test process can be manually loaded, automatically loaded, or according to the set torque, time, etc. Curve loading, can carry out motor type test, durability test, temperature rise test, etc. For more test products of our company, you can visit our website www.5iziyuan.com or call 400-111-3688 for consultation, welcome to call!
|
